LPD 53.7A (80LPD) General Pumps
EBARA 53.7A uses a low-noise, TEFC (Totally Enclosed Fan Cooled) motor and can be installed indoors and outdoors.The impeller and casing developed using our proprietary analytical technology significantly improve.80LPD caliber universal pump, EBARA 53.7A The pump can be disassembled and inspected without disassembling the pipes.
In the detailed model name, LPD represents the model, 2 represents the number of motor stages, HC represents the impeller code, 5 represents the frequency of 50 Hz, 4 represents the motor power of 4 kW, 80 represents the inlet and outlet diameters, H represents 10 bar type: None, 16 bar type: H.
As part of EMAC, PumpMac offers a wealth of high-quality pump drive power group options, WPT PTO, Advance gearboxes and pump heads, and custom water pump groups. We also have a set of NFPA20 standard engine power group accessories, including intake shut-off valves, DC contactors, engine control panels, jacket water heaters, etc.
We provide full life cycle services to all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from troubleshooting to overhaul technical support.
Advantages of LPD 53.7A (80LPD) General Pumps
Small size and light weight.
The pipeline is linear and can be installed in the middle of the pipeline with a small installation volume.
The motor uses a low-noise, fully enclosed, splash-proof outdoor motor. It can be installed indoors or outdoors (all single-phase, except for three-phase 0.15KW).
The pump can be disassembled and repaired without disassembling the pipeline system.
It can be used at high temperature (100°C) and high pressure (suction pressure up to 0.69MPa), so it is most suitable for use as a circulating pump.
It uses a mechanical seal, which is easy to maintain.
Technical Specifications
| Model: | 25LPD/32-80LPD |
| Medium: | Clear water*1 0~100C |
| Suction Lift: | -6m (20C) |
| Inhalation allowed: | Pressure/0.2MPa |
| Structure/Impeller: | Closed type |
| Structure/Shaft seal: | Mechanical seal |
| Structure/Bearing: | Sealed ball bearings (inside the motor) |
| Connect/Suction Side: | Cast iron |
| Connect/Discharge side: | Cast Iron |
| Material/Pump body: | FC200 |
| Material/Impeller: | SUS304 |
| Material/Axis: | SUS304 |
Water Pump Model | Water Pump Diameter | Motor Poles | Synchronous Speed | Motor Power | Frequency |
| LPD5.05S | 25LPD | 2 | 3000min-1 | 00.45 kW | 50 hz |
| LPD5.08S | 25LPD | 2 | 3000min-1 | 00.8 kW | 50 hz |
| LPD5.15S | 25LPD | 2 | 3000min-1 | 0.15 kW | 50 hz |
| LPD5.25S | 25LPD | 2 | 3000min-1 | 0.25 kW | 50 hz |
| LPD5.15 | 25LPD | 2 | 3000min-1 | 0.15 kW | 50 hz |
| LPD5.25S | 32LPD | 2 | 3000min-1 | 0.25 kW | 50 hz |
| LPD5.4S | 32LPD | 2 | 3000min-1 | 0.4 kW | 50 hz |
| LPD5.25A | 32LPD | 2 | 3000min-1 | 0.25 kW | 50 hz |
| LPD5.4A | 32LPD | 2 | 3000min-1 | 0.4 kW | 50 hz |
| LPD5.75A | 32LPD | 2 | 3000min-1 | 0.75 kW | 50 hz |
| LPD5.25S | 40LPD | 2 | 3000min-1 | 0.25 kW | 50 hz |
| LPD5.4S | 40LPD | 2 | 3000min-1 | 0.4 kW | 50 hz |
| LPD5.25A | 40LPD | 2 | 3000min-1 | 0.25kW | 50 hz |
| LPD5.4A | 40LPD | 2 | 3000min-1 | 0.4 kW | 50 hz |
| LPD5.75A | 40LPD | 2 | 3000min-1 | 0.75 kW | 50 hz |
| LPD51.5A | 40LPD | 2 | 3000min-1 | 1.5 kW | 50 hz |
| LPD52.2A | 40LPD | 2 | 3000min-1 | 2.2 kW | 50 hz |
| LPD5.4S | 50LPD | 2 | 3000min-1 | 0.4 kW | 50 hz |
| LPD5.4A | 50LPD | 2 | 3000min-1 | 0.4 kW | 50 hz |
| LPD5.75A | 50LPD | 2 | 3000min-1 | 0.75 kW | 50 hz |
| LPD51.5A | 50LPD | 2 | 3000min-1 | 1.5 kW | 50 hz |
| LPD52.2A | 50LPD | 2 | 3000min-1 | 2.2 kW | 50 hz |
| LPD53.7A | 50LPD | 2 | 3000min-1 | 3.7 kW | 50 hz |
| LPD5.75A | 65LPD | 2 | 3000min-1 | 0.75 kW | 50 hz |
| LPD51.5A | 65LPD | 2 | 3000min-1 | 1.5 kW | 50 hz |
| LPD52.2A | 65LPD | 2 | 3000min-1 | 2.2 kW | 50 hz |
| LPD53.7A | 65LPD | 2 | 3000min-1 | 3.7 kW | 50 hz |
| LPD55.5A | 65LPD | 2 | 3000min-1 | 5.5 kW | 50 hz |
| LPD51.5A | 80LPD | 2 | 3000min-1 | 1.5 kW | 50 hz |
| LPD52.2A | 80LPD | 2 | 3000min-1 | 2.2 kW | 50 hz |
| LPD53.7A | 80LPD | 2 | 3000min-1 | 3.7 kW | 50 hz |
| LPD55.5A | 80LPD | 2 | 3000min-1 | 5.5 kW | 50 hz |
| LPD57.5A | 80LPD | 2 | 3000min-1 | 7.5 kW | 50 hz |
| LPD511A | 80LPD | 2 | 3000min-1 | 11 kW | 50 hz |
| ——END—— | |||||
| serial number | Part Name | Material | Number |
| 001 | Pump casing | FC200 | 1 |
| 011 | Pump cover | SUS304 | 1 |
| 021 | impeller | SUS304 | 1 |
| 048 | Impeller nut | SU5304 | 1 |
| 107 | Bushing ring | CAC406 | 1 |
| 111 | Mechanical seal | – | 1 |
| 211 | Exhaust valve | C 3604BD | 1 |
| 800 | Motor | – | 1 |
| 830 | axis | SUS304 | 1 |
Safety Instructions and Preventive Maintenance Guide
Requirements for use
Pumps play a significant role in a variety of industries and applications, ensuring the smooth movement of liquids and gases. However, in order to maintain top performance and safety, it is essential to adhere to routine maintenance procedures and safety recommendations. This guide aims at providing the detailed information about pump safety and preventive maintenance.
Safety Instructions
1. Read the Manual
Before using EBara pumps, read and understand the handbook thoroughly. Make sure you understand the pump’s specifications, capabilities, and safety precautions.
2. Proper Installation
Ensure the pump is put appropriately according to the guidelines. Improper installation can cause operating inefficiencies and safety issues.
3. Ventilation
Operate pumps in well-ventilated areas to prevent the buildup of potentially harmful gases or vapors. If working in confined spaces, use proper ventilation equipment.
4. Emergency Shutdown Procedures
Familiarize yourself with emergency shutdown procedures in case of malfunction, leakage, or any other hazardous situation. Ensure all personnel know how to operate emergency shutdown mechanisms.
5. Regular Inspections
Conduct routine inspections of the pump and its components for signs of wear, damage, or leaks. Address any issues promptly to prevent accidents or system failures.
6. Chemical Compatibility
If handling hazardous chemicals, ensure the pump materials are compatible with the fluid being pumped or refer our chemical compatibility chart for more information. Incompatible materials can lead to corrosion, leaks, or chemical reactions.
Preventive Maintenance
1. Regular Lubrication
Keep bearings, seals, and other moving parts properly lubricated. Insufficient lubrication can lead to premature wear and breakdowns.
2. Inspect Seals and Gaskets
Check seals and gaskets for wear, damage, or leaks regularly. Replace any worn or damaged seals to prevent fluid leakage and maintain pump efficiency.
3. Check Motor Alignment
Ensure the pump motor is properly aligned with the pump shaft to prevent excessive wear on bearings and seals. Misalignment can lead to premature failure and costly repairs.
4. Replace Worn Parts
Keep an inventory of spare parts and replace worn or damaged components as needed. Regularly check wear parts such as impellers, seals, and bearings for signs of deterioration.
5. Schedule Maintenance
Develop a preventive maintenance schedule based on manufacturer recommendations and operating conditions. Regular maintenance helps prevent unexpected breakdowns and extends the life of the pump.
6. Document Maintenance Records
Keep detailed records of all maintenance activities, including inspections, repairs, and replacements. This information helps track the pump’s performance over time and identify any recurring issues.
By following these safety instructions and preventive maintenance practices, you can ensure the safe operation and longevity of your pumps while minimizing the risk of accidents or downtime. Remember, prioritizing safety and proactive maintenance is key to maximizing pump efficiency and reliability.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
